Instruction Manual
C
HAPTER
3:
Applying Power for the First Time
Setup Checklist
As an option, the drive and motor could be set up on a test bench before installation, by following
the Start-up Procedure.
1. Remove all interface wiring.
2. Remove the cover and set jumpers P6 through P9A. See Figure 2.1 on page 2-2 and
“Internal Connections (FAC, RAC and INH)” on page 2-11.
3. Verify that fuses F1 and F2 are good. See “Checking and Replacing the Fuses” on
page 4-2.
4. Ensure transformer is sized correctly for the application. Refer to “Transformer Sizing”
on page 2-3.
5. Verify the transformer selected can provide enough voltage for the application. This can
be determined by looking at the maximum speed of the application and the voltage
constant (K
E
) of the motor selected.
6. Check that the incoming AC or DC voltage is correct.
Do not apply more than 85 VAC or 120 VDC to TB1 pins 6 and 7.
Verify fusing per wiring diagrams in “AC and DC Power Connections” on page 2-4.
7. Install drive. Refer to “Mounting” on page 2-3.
8. Replace cover.
Intro
!
WARNING
If the polarity of the tachometer is not connected to the drive correctly, the motor
will run away which could damage the load and may cause bodily injury.
K
E
Max Speed
×
1000
,
----------------------------------------
Motor Winding Resistance Peak Current
×()
+1.5
×
DC bus voltage=
K
E
= Volts/krpm
Max. Speed = krpm
Motor Winding Resistance = Ohms
Peak Current = Amps
1.5 = 50% safety and losses
Tapped voltage from transformer
DC bus voltage
2
-------------------------------------
≥
