CYCLE, SYSTEMS & COMPONENTS
Water Temperature Test Mode
This test is for testing the thermistor in the sump as well as the control.
Start a Normal wash cycle and allow the dishwasher to fill and wash for 2 minutes,
at which time, press the Start/ Cancel pad twice (2) which will stop the dishwasher
and send it to idle. With the dishwasher in idle, press and hold the Normal wash
and the Start/ Cancel pads simultaneously to start the test. The test will show a
two digit display for the temperature of the water (from 0°F to 99°F). If the water
temperature is over 99°F, a decimal point will be displayed to show 100°F, then the
added degrees over. This reading will be updated every three seconds until the
Start/ Cancel pad is depressed to stop the test.
Soil Sensor Test Mode
This tests the sensor for proper operation as well as the value that the
sensor is detecting.
To activate the test you must press and hold the Heavy and Start pads
simultaneously. When the test mode is activated, the digit display will show the
turbidity value of the sensor. This display will be a voltage reading in the decimal
value. To terminate this test press the start pad.
Step
Description
Time
Water Valve
Wash Motor
Drain pump
Heater
Dispenser
Fan
Sensing LED
Drying LED
Sanitized LED
Dispenser Low
Clean LED
1 Fill / Dispenser 59 1 0 0 0 0 0 1 0 0 0 0
2 Fill / Dispenser / Wash 21
*
1 0 0 1 0 1 0 0 0 0
3 Wash / Heat 45 0 1 0 1 0 0 1 0 0 0 0
4 Pause 0.6 0 0 0 0 0 0 1 0 0 0 0
5 Wash / Heat 75 0 1 0 1 0 0 0 0 0 0 0
6 Wash / Heat / Dispenser 80 0 1 0 1 1 0 0 0 0 0 0
7 Drain 90 0 0 1 0 0 0 0 0 0 0 0
8 Dry 90 0 0 0 1 0 1 0 1 0 0 0
Completion 460.6 1 0/1 1
* Dynamic fill - water valve is open until pressure switch is closed
