40
PARTS BREAKDOWN
TUB AND FRAME
POS. NO PART NO DESCRIPTION
001 5304434827 Screw,extrudetite ,M4 x 10 PNHD PH
003 5304434829 Screw,flange HD ,#7-19 x 8 hi/lo
004 5304434830 Screw,Pan HD hi/lo ,#7-19 x 1/2
006 5304434832 Screw,taptite ,M5 x 6 Truss HD ,ZC
007 5304434833 Screw,PH pan HD ,#8 x 19
008 5304434834 Screw,alkon TT0812 ,#8 x 13 ,black
009 5304434835 Screw,Truss PH HD ,M5 x 16 ,s/s
010 5304434836 Screw,E4 torx ,M5 x 13 PH HD
030 5304434841 Lock Nut,whiz ZY ,M5 x 0.8 hex
202 5304434860 Catch,door
205 5304434861 Seal,retainer ,door seal
206 5304434862 Retainer,door seal ,RH
207 5304434863 Retainer,door seal ,LH
208 5304434864 Seal,door ,black
209 5304434865 Rail,upper rack
210 5304434866 Stop,upper rack rail
211 5304434867 Support,roller assy.
214 5304434868 Spring,door hinge
215 5304434869 Support,door spring
216 5304434870 Hinge,door ,LH
217 5304434871 Guard Pad,door hinge ,LH
218 5304434872 Clip,door pivot
219 5304434873 Washer,sealing
221 5304434874 Panel,front cover
222 5304434875 Bracket,kickplate ,LH
223 5304434876 Panel,adj. kickplate ,black ,top
224 5304434877 Panel,adj. kickplate ,black ,bottom
225 5304434878 Insulation,kickplate
226 5304434879 Bracket,kickplate ,RH
227 5304434880 Cover,junction box
229 5304434881 Hinge,door ,RH
230 5304434882 Guard Pad,door hinge ,RH
232 5304434883 Leg,leveling assy.
235 5304434884 Support,motor/pump
237 5304434885 Cone,door guide
