44
PARTS BREAKDOWN
WRAPPER AND TRIM
POS. NO PART NO DESCRIPTION
001 5304434827 Screw,extrudetite ,M4 x 10 PNHD PH
005 5304434831 Screw,c/sunk #6 HD ,#8 x 11 AB
015 5304434839 Screw,SAB ,8 x 1/2 PN HD ,ZC
101 5304434853 Bumper,wrapper top
102 5304434854 Trim,cabinet top ,stainless
103 5304434855 Trim,cabinet side ,stainless ,LH
104 5304434856 Trim,cabinet side ,stainless ,RH
105 5304434857 Extrusion,side trim
108 5304434858 Panel,back
109 5304434859 Clip,back panel
