11.2 NTC 2 (Inlet Control
Thermistor) Accessibility
Remove the screw from the
Air Duct (See Fig. 1), remove
Intlet Control Thermistor
(See Fig. 2) and unplug the
connectors (See Fig. 3).
11.3 NTC 1 (Outlet Control
Thermistor) Accessibility
Remove the screw, remove Outlet Control Thermistor
in shown direction (See Fig. 1) and unplug the
connectors (See Fig. 2).
11.4 Fire Containment Thermostat
Accessibility
Remove the Screws
(See Fig. 1) and unplug
the connector of Fire
Containment Thermostat
(See Fig. 2).
11.5 Outlet Thermal Limiter
Accessibility
Step: 1
Remove the screw from the exhaust tube which is
fitted with the base of Dryer (See Fig. 1), pull out the
exhaust tube (See Fig. 2) and unplug the connector of
Outlet Thermal Limiter (See Fig. 3).
Rear Panel Accessibility
