Electrolux EFMG417SIW - Burner Accessibility; Igniter Accessibility; Inlet Thermal Limiter Accessibility; High-Limit Thermostat Accessibility

33
11.7.2 Burner Accessibility
Remove the screws (1, 2, 3) (See Fig. 8 and 9) which fits with the heater bracket.
11.7.4 Inlet Thermal Limiter Accessibility
Inlet Thermal Limiter Accessibility for Gas model is same as the Electrical model. Please refer Section 11.6.1.
11.7.5 High-Limit Thermostat Accessibility
High-Limit Thermostat Accessibility for Gas model is same as the Electrical model. Please refer Section 11.6.2.
11.7.3 Igniter Accessibility
NOTE
Igniter is soft brittle material, so handle it carefully.
Remove the screw (1) and push the Igniter (2) from the Burner Assembly stand as shown in Fig. 10.
Rear Panel Accessibility
Fig. 8 Fig. 9
Fig. 10
