Electrolux EFMG417SIW - Page 38

38
Step: 3
In order to remove the Motor and the Blower, follow
the steps mentioned below:
• Remove all holders (metal clamp) (See Fig. 1).
• Hold tightly the Pulley / Shaft at belt
connecting area by wrench and remove fan
(Blower) by loosening the Nut (See Fig. 2).
• Now you can remove Blower Assembly and
Motor separately.
Motor Assembly Accessibility
Step: 2
Remove the screw from Blower Assembly from Front
side of the Dryer (See Fig. 1) and Slide Motor Blower
Assembly towards Front side of the Dryer (See Fig. 2).
