Electrolux T5350 - Page 31

Service Manual
31
Remount the motor module in the machine.
Fasten the belts and make sure the belts are in position. Fasten the belt tensioner and connect the motor cable.
Remount the rear panel.
On machines without reversing
Disconnect the power to the machine.
Demount the rear panel.
Disconnect the motor cable (A).
Loosen the belt tensioner (B).
Loosen both of the belts (C).
Demount the fan module.
fig.7875
Demount the screw and pull off the fan wheel.
fig.7874
