14.2ReplacementofI/Omodule
I/Omoduletype8andI/Omoduletype2areinstalledinthesameway.IfthemachinehasI/O
moduletype2,itislocatedonI/Omoduletype8.TheillustrationshowsreplacementofI/O
moduletype8.
Disconnectthepowertothemachine.
Demounttheupperrearpanel.
162
g.7442
Removetheelectricalconnectionsonthemodule.(Notethepositionoftheconnections).
Removethemodulebyliftingittowardsyouandupabitandthenpushingittotheleft.
163
