Electrolux T5675 - Heating Sensor (PT100)

12
Sensorsandoverheatingthermostats
5.1.2Heatingsensor(PT100)
Description
Theheatingsensorisplacedontheheatingmoduleonthebackofthemachine.
TheheatingsensormeasuresthetemperatureintheinletairandthesignalisreturnedtotheCPU.
TheCPUturnstheheatingunitoffwhentheinletairthermistorindicatesthattherequired
temperaturehasbeenreached.
Replacementofheatingsensor(PT100)
Disconnectthepowertothemachine.Gasheatedmachine:Shutoffthemanualgasvalve.
Demounttheupperrearpanel.
Disconnecttheheatingsensorandremoveit.Connectthenewheatingsensorandputitinposition.
Makesurethesensorgetsallthewaydown.
ElandGasheatedmachine.
Steamheatedmachine.
Remounttheupperrearpanel.
