Electrolux T5675 - Control System CPU and Connections

Controlpanel
93
12.1Controlsystem
12.1.1Description
ThecontrolsystemCPUiselectronicandcomprisesacircuitboardcontainingmicroprocessor,
programmemory,serialinterfacetothemotor,I/O-boardsetc.
ThecontrolsystemCPUreceivesitspowerfromaseparatepowersupplyunit.
142
g.7356
Thecontrolsystemreceivesinformationaboutinputsliketemperaturesensors,RMC,vacuum,door
statusetc,andactivatesoutputslikedrum,fanandheatcontrol.
