Electrolux T5675 - Converting Instructions

58
Heatingunit,gas
9.6Convertinginstructions
NotapplicableforJapan.
•Disconnectthepowertothemachine.
•Demountthelowerbackpanel.
•Removetheairreducingplates.
•Removethenozzle(1).
•Mountthenewsuppliednozzle.
•Mountthenewairreducingplatesaccordingtothetable.
83
1
g.7182
•Loosenthemeasuringbranchscrew(2)1/4turn;connectamanometertothemeasuringbranch.
•Connectthepowertothemachineandselectaprogramwithheat.
•Startthemachine.
•Setthecorrectnozzlepressureaccordingtothetableonsettingscrew(4)underthecover
screw(3).
84
2
3, 4
g.7120
