Electrolux T5675 - Heating Sensor (NTC-Sensor)

Sensorsandoverheatingthermostats
15
5.2.2Heatingsensor(NTC-sensor)
Description
Theheatingsensorisplacednexttothefanmotoronthebackofthemachine.
TheheatingsensormeasuresthetemperatureintheoutletairandthesignalisreturnedtothePCB.
ThePCBturnstheheatingunitoffwhentheoutletairthermistorindicatesthattherequired
temperaturehasbeenreached.
Replacementofheatingsensor(NTC-sensor)
Disconnectthepowertothemachine.
Demountthelowerrearpanel.
Disconnecttheheatingsensorandremoveit.Connectthenewheatingsensorandputitinposition.
Makesurethesensorgetsallthewayin.
⑦
g.W00250A
Remountthelowerrearpanel.
