Electrolux T5675 - Replacement of the Belt Around the Motor Pulley

38
Motor
Fastenthebelt(B)andthewire(A).Rotatethedrumtomakesurethatthebeltisinposition.
Tightenthebelttensionerwithatorquewrenchbypullingthetensionplate(E)clockwiseuntil
itisinposition.
Checkthebelttensionwithafrequencymeaterorsimilar.Thefrequencyshallbe75Hz±5Hz.
Adjustifnecessary.
50
A
B
E
B
g.7220D
Remountthecoverpanelandtherearpanels.
Note!
ThemachinewillNOTworkwithoutthecoverpanel.
7.5Replacementofthebeltaroundthemotorpulley
Disconnectthepowertothemachine.
Demountthetworearpanels.
51
g.7215E
