Sensorsandoverheatingthermostats
11
5Sensorsandoverheatingthermostats
5.1Inletair
5.1.1Overheatingthermostat
Description
Theinletoverheatingthermostatisplacedontheheatingmoduleonthebackofthemachine.
Theinletoverheatingthermostatopensintheeventofoverheatingandshutsoffthemachine.
Resetting
Disconnectthepowertothemachine.Gasheatedmachine:Shutoffthemanualgasvalve.
Demounttheupperrearpanel.
Presstheresetbutton(A)ontheoverheatingthermostat.
Note!
Resettingmustnotbedonebeforethecauseforoverheatingisveriedandresolved.
④
A
g.W00252
Remounttheupperrearpanel.
Replacementofoverheatingthermostat
Disconnectthepowertothemachine.Gasheatedmachine:Shutoffthemanualgasvalve.
Demounttheupperrearpanel.
Disconnecttheoverheatingthermostatandremoveit.Connectthenewoverheatingthermostat.
ElandGasheatedmachine.
Remounttheupperrearpanel.
