Electrolux T5675 - Page 41

Motor
41
Inordertoloosenthebelt,rstloosenthefourscrewsabit.
56
1 2 3 4
g.490377800
Loosenthebelt(C)fromthe“motorarm”.
57
C
g.7224B
Putthenewbeltinposition(C)andtightenthescrews.Startbytightening1and3abit.Thighten4
andcheckthebelttensionwithafrequencymeaterorsimilar.Thefrequencyshallbe80Hz±5.
Adjustwith4ifnecessary.Thentighten2withtighteningtorque80Nm±5andnally1and3with
tighteningtorque6Nm±1againwhenallisinposition.Checkthat5istightened.
58
1 2 3 4
5
g.49077800A
