Electrolux T5675 - Page 77

Drum
77
Fastentheboltandthewasherandremountthebearinghouse.Usetighteningtorque20Nm±
3Nm.
OnmachineswithRMC;pulltheRMCangebackinpositionandtightenthescrew.Usetightening
torque5Nm±0.5Nm.
Pushthebeltfromtheouterdrumontotheinnerdrumandmakesureitisinposition.
Fastenthebelt(B)andthewire(A).Rotatethedrumtomakesurethatthebeltisinposition.
Tightenthebelttensionerwithatorquewrenchbypullingthetensionplate(E)clockwiseuntil
itisinposition.
Checkthebelttensionwithafrequencymeaterorsimilar.Thefrequencyshallbe75Hz±5Hz.
Adjustifnecessary.
114
A
B
E
B
g.7220D
