ELIS PLZEŇ a. s.
Design, Assembly and Service Manual
Page 13 of 69
Electromagnetic flowmeter FLONET FN20xx.1
ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, Phone: +420/377 517 711, Fax: +420/377 517 722 Es90420K/c
4.1.6. Dimensions of flanged sensor
D
DN
l
L
d
A
Dimensions of sensor with flanges according to EN1092-1.
Pressure
rating
DN
D [mm]
D [mm]
A* [mm]
L [mm]
L [mm]
Weight
[ kg ]
6
90
170
PN 25
8
90
170
10
90
170
15
95
62
164
200
66
2.9
20
105
62
170
200
66
3
PN 40
25
115
72
180
200
96
3.9
32
140
82
197
200
96
5.5
40
150
92
207
200
96
6.1
50
165
107
225
200
96
8.1
65
185
127
245
200
96
10
80
200
142
260
200
96
12.3
PN 16
100
220
162
280
250
96
15.3
125
250
192
310
250
126
18.9
150
285
218
344
300
126
26
200
340
274
399
350
211
36
250
395
370
475
450
211
60
300
445
420
525
500
320
68
350
505
480
584
550
320
92
PN 10
400
565
530
642
600
320
158
450
615
581
695
600
320
150
500
670
640
752
600
320
177
600
780
760
870
600
320
288
700
895
880
990
700
420
800
975
960
1100
800
420
427
PN 6
900
1075
1040
1185
900
520
1000
1175
1140
1290
1000
520
500
1200
1405
1340
1510
1200
520
680
* Dimension A (sensor height) is without transmitter housing (or terminal box in the remote
version).
The sensor weight is an indicative value.
