Page #42 background imageLoading...
Page #42 background image
ELIS PLZEŇ a. s.
Design, Assembly and Service Manual
Page 42 of 69
Electromagnetic flowmeter FLONET FN20xx.1
ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, Phone: +420/377 517 711, Fax: +420/377 517 722 Es90420K/c
7.1.7. Production data
The first three menu items, i.e. Production Data, Serial Number and Software, give basic information about
the electromagnetic flowmeter and as such cannot be edited. The other items, i.e. Sensor Constants,
Excitation Frequency, Suppressed Flow Rate, Language, Sensor Number, Sensor DN, Errors, Dose
Correction, Flow Direction and Base Frequency can be changed by the user unless the flowmeter is certified
and used as an invoicing meter; in such cases the sensor constants, excitation frequency and suppressed
flow rate are protected against unauthorised modification.
Menu: Production data, press the key.
Production date
Serial number
Software
Sensor constants
Excitation freq.
Suppressed flow
Language
Sensor number
Sensor DN
Errors
Dose correction
Flow direction
Base frequency
The two-line display will always show two selected menu items. To browse through the menu items, press
repeatedly the (direction downwards) and keys (upwards). To select a particular menu item, press the
key.
Menu: Production data, press the key / Production date, press the key
The display will read Production Date dd mm yyyy”. This information cannot be edited. To return to the
Production data menu, press any key, for example the key. The menu will reappear on the display.
Menu: Production data, press the key / Serial number, press the key
The display will read Serial Number xxxxxrr”. This information cannot be edited. To return to the Production
data menu, press any key, for example the key. The menu will reappear on the display.
Menu: Production data, press the key / Software, press the key
The display will read Software v.xxxxx/xx”. This information cannot be edited. To return to the Production
data menu, press any key, for example the key. The menu will reappear on the display.
Menu: Production data, press the key / Sensor constants, press the key
Constant 1
Constant 2
To browse through the menu items, use the (direction downwards) and key (upwards). Select the
desired item and press the key. The constant value will appear on the display. Should you wish to change
this value, use the key to place the cursor under the selected figure and increase/decrease the same
using the and keys, respectively. The sensor constants shall be set at the values indicated on the
sensor nameplate. Any difference in the values of constants results in the incorrect calibration of flowmeter.
