Electromagnetic flowmeter FLONET FN20xx.1
ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, Phone: +420/377 517 711, Fax: +420/377 517 722 Es90420K/c
Communication
Communication consists of transmission of individual data packets. To ensure correct function of a
communication network, each station must have a different address. On delivery, all electromagnetic
flowmeters will have the following setting of communication parameters: Address 1, Group 1, Speed 9600Bd,
Parity SL. Communication uses the FLOSET 2.0 program package.
The communication protocol is not included in this brochure; it can be obtained from the meter manufacturer
on request.
Menu: Serial line, press the key
Address
Group
Baud rate
Parity
The two-line display will always show two of the menu items. To browse through the menu, use the
(direction upwards) and keys (downwards). Select the desired item and press the key.
Menu: Serial line, press the key / Address, press the key
The display will read “Address xxx”. Replace “xxx” by a number from 1 to 255, being the meter address.
Press the key. The display will show the message “Value Entered Press Any Key”. Press any key,
preferably the key. This command will take you back to the Serial Line menu.
Menu: Serial line, press the key / Group, press the key
The display will read “Group xxx”. Replace “xxx” by a number from 1 to 255, being the designation of a group
of electromagnetic meters. Press the key. The display will show the message “Value Entered Press Any
Key” Press any key, preferably the key. This command will take you back to the Serial Line menu.
Menu: Serial line, press the key / Baud rate, press the key
All equipment connected to a particular communication line branch shall use the same communication
speed. There are six optional selections of speed:
1200Bd
2400Bd
4800Bd
9600Bd
19200Bd
38400Bd
The two-line display will always show two of the menu items. To browse through the menu, use the key
(direction upwards) and (downwards). Select the desired item and press the key. This action will bring
the display to the Serial Line menu.
Menu: Serial line, press the key / Parity, press the key
Parity --
Parity SL
Parity SS
Parity LS
Parity LL
The two-line display will always show two of the menu items. To browse through the menu, use the
(direction upwards) and key (downwards). Select the desired item and press the key. This action will
bring the Serial Line menu on the display.
To return to the basic configuration menu, item Serial Line, press the key.
