ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, Phone: +420/377 517 711, Fax: +420/377 517 722 Es90420K/c
7. CONFIGURATION
The electromagnetic flowmeter can be configured in two ways: using a computer connected to the serial
meter interface or using its own keypad. The following description relates to the keypad configuration
procedure.
The keypad includes four keys labelled with the following symbols:
1. Symbol , the “roller” key, indicates a downward movement
2. Symbol , a movement to the right in the direction of arrow; an upward direction
3. Symbol , a password entry key, an upward movement in the direction of arrow; movement back to the
menu;
4. Symbol , the “Enter” key (command confirmation).
In any menu, the selected line is on the first line with the first character blinking.
Entering the configuration mode, movement within a menu and data saving
To enter the configuration mode, press the key and then the key. The configuration mode is
protected against unauthorised access by a password (a four-digit number) that needs to be entered before
accessing the basic configuration menu. Upon delivery from the manufacturing plant, every new meter has
a default password of 0000.
Display reading: Password
With a new meter, enter password 0000 and confirm by pressing the key. If you have already chosen your
own password, enter the same and confirm by pressing the key. Prior to leaving the configuration mode,
the password can be changed without any limitation.
Use the key to move the cursor to the right. Upon reaching the rightmost position, the cursor will return to
the left side of the line. The cursor is a short horizontal line located under the character we wish to
edit/change.
Use the key to change the selected character in the upward direction, or the key in the downward
direction. Upon reaching the last character available, the first eligible character will reappear.
After completing the editing action, confirm your choice of password by the button. Should you enter an
incorrect password, the display will read “Incorrect password Try again” while the program will return to the
data display mode.
Display reading: confirmation of correct password entry: Password OK. Press any key.
With the display reading “Password OK Press any key”, press any key (preferably ) to enter the basic
configuration menu.
