Page #52 background imageLoading...
Page #52 background image
ELIS PLZEŇ a. s.
Design, Assembly and Service Manual
Page 52 of 69
Electromagnetic flowmeter FLONET FN20xx.1
ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, Phone: +420/377 517 711, Fax: +420/377 517 722 Es90420K/c
The initial flowmeter setting procedure: With the meter power supply turned off, press simultaneously and
keep pressed the and keys, turn on the power, and wait till the display starts showing the flowrate
values. This operation is used to activate the meter transmitter in production. The initialisation procedure
cancels previous meter calibration and output settings and replaces these by factory-preset parameters.
Therefore, in the next step, the customised meter setting needs to be performed. There are two possible
methods available to do that:
1) Parameter setting via the meter keypad. Enter the configuration menu using password “0000” (see the
Project design, assembly and service manual FLONET FN20xx.1). Enter the parameters specified on the
sensor rating plate: excitation frequency, threshold (suppressed) flow rate, language, sensor number and
DN. Further it is necessary to define liquid volume units to be displayed and to set up the output
configuration.
2) Parameter setting using a computer and the USB serial communication line. The configuration software
(FLOSET 2.0) is supplied by the manufacturer, ELIS PLZEŇ. Fill in the meter specific data into the
respective FLOSET 2.0 tables and store them into the meter memory unit. A more practical way of
parameter setting is re-writing the pre-set values by the meter configuration file (system production series
number.fln). Feed the configuration file into the FLOSET 2.0 program and store it into the meter memory.
The configuration file can be obtained from the meter manufacturer.
