ELNA 3210 - Replacing the Bobbin Holder and Needle Plate; Changing the Light Bulb

102
Changing the Light Bulb
The sewing light is located behind the face plate.
UNPLUG THE MACHINE.
Wait until the bulb is COOL before you touch it!
Remove screw cap , screw and face
plate .
Depending on model:
(A) To remove: pull out bulb from socket.
To replace: insert bulb into socket.
(B) To remove: Push up and twist to the left.
To replace: Push up and twist to the right.
Attach face plate and insert screw and screw cap.
NOTE: Replace bulb with same type and rating, Model
3210: 15 W, Model 3230: 12V, 5W.
2
1
3
3
2
1
1
2
3
1
2
3
Wipe gently inside the hook area with soft, dry cloth. (You
can also use a small vacuum cleaner.)
Replacing the Bobbin Holder and Needle Plate
Insert the bobbin holder so the knob fits next to the
stopper in the hook area.
Replace the needle plate and align the hook . Replace
the screws.
After cleaning, be sure to replace the needle, presser
foot and bobbin.
(A)
(B)
