4. Push bobbin winder spindle to the right. (Model 3230
only - the LCD readout will display “Bobbin winding”.)
5. Holding the free end of the thread, press the foot
control. Stop the machine when it has made a few
turns and cut the thread tail close to the hole in the
bobbin. Press the foot control again. When the
bobbin is fully wound, it will stop automatically.
6. Return the bobbin winder spindle to the left and cut
the thread.
NOTE: Do not move the bobbin winder spindle when the
machine is running.
Additional Spool Pin
The additional spool pin can be used to wind an extra
bobbin without unthreading the machine.
PROCEDURE: Insert the spool stand and the
additional spool pin in the hole (located in front of
spool pin). Place the felt and spool on the pin with the
thread coming off the spool as shown.
