Operating the machine
16
Now the vertical laser (10) for sensing the home position of the arm (3) is
continuously ON. This can be seen by looking at the sensor (11) underneath the
laser (10), see figure arm installation.
If the laser (10) is ON and there is no beeping to hear, it means that the sensor
(11) is sensing the laser beam.
Interrupt the beam between the laser (10) and the sensor (11) to verify the correct
functioning of sensor (11) and beeper.
If the laser (10) is ON and the beeper is beeping, although the beam is not
interrupted, this means that the beam doesn’t hit the sensor (11).The beeper
signalizes this condition. In this case the laser (10) should be mechanically
adjusted so that the beam will be in the middle of the sensor (11). The beeper will
stop beeping.
It is not enough if simply the beeping stops. Make sure that the beam is in the
middle of the sensor.
1.11 Horizontal laser
Eye injury
Laser beam
– Laser beam has high energy and can injure your eyes.
• Don’t look directly into the laser beam.
