Chapter 3 61
6. Remove the four securing screws (two each side) from the LCD module.
7. Carefully remove the LCD module from the chassis.
Step Size Quantity Screw Type
LCD Module
(red callout)
M2.5*8 2
LCD Module
(blue callout)
M2.5*5 2
