62 Chapter 3
Removing the Upper Cover
1. See “Removing the Battery Pack” on page 44.
2. See “Removing the Lower Covers” on page 45.
3. See “Removing the LCD Module” on page 60.
4. Turn the computer over. Remove the eight screws on the bottom panel.
5. Turn the computer over. Remove the seven screws on the top panel.
Step Size Quantity Screw Type
Upper Cover M2.5*8 8
Step Size Quantity Screw Type
Upper Cover M2.5*5 7
To Next Page
