Disk-array enclosure (DAE)
EMC VNX7500 Parts Location Guide 55
Table 37 lists the part number label location, part number, description, and whether it is a
FRU or CRU.
Table 37 4U, 60 (2.5- or 3.5-inch) DAE ICM and power supply part numbers
Part number label
location
(Figure 49 on
page 54) Part number Description FRU CRU
1 303-172-000C ICM B
1

2 071-000-545 Power supply B
2
, dual AC input,
1300 W, +12 V

Note: If the 4U, 60 (2.5- or 3.5-inch) DAE is located higher than 31U in the Dense rack, then both
the ICM and power supply are FRUs.
1. The rear of the 4U, 60 (2.5- or 3.5-inch) DAE has the ICM on opposite sides of the DAE. In other words, ICM A
is located on the left of the DAE and ICM B is located on the right (Figure 49 on page 54).
2. The rear of the 2U, 60 (2.5- or 3.5-inch) DAE has the DAE power supplies between ICM A and B. In other
words, power supply A is located on the left of the DAE and power supply B is located on the right (Figure 49
on page 54).
