98 Quantum MP User Guide
www.emersonct.com Issue: A4
Parameter
Range(
) Default()
Type
1.01 Speed reference selected {di01, 0.36} ±MAX_SPEED_REF rpm RO Bi NC PT
1.02 Pre-skip filter reference ±MAX_SPEED_REF rpm
RO Bi NC PT
1.03 Pre-ramp reference {di02, 0.37} ±MAX_SPEED_REF rpm
RO Bi NC PT
1.04 Reference offset ±10,000.0 rpm 0.0 RW Bi US
1.05 Jog reference 0 to 1,000.0 rpm 0.0 RW Uni US
1.06 Maximum reference clamp {SE02, 0.23} SPEED_LIMIT_MAX rpm 1,000.0 RW Uni US
1.07 Minimum reference clamp {SE01, 0.22} ±SPEED_LIMIT_MAX rpm 0.0 RW Bi PT US
1.08
Negative minimum reference
clamp enable
OFF (0) or On (1) OFF (0) RW Bit US
1.09 Reference offset select OFF (0) or On (1) OFF (0) RW Bit US
1.10 Bipolar reference enable OFF (0) or On (1) OFF (0) RW Bit US
1.11 Reference enabled indicator {di11, 0.46} OFF (0) or On (1)
RO Bit NC PT
1.12 Reverse selected indicator {di12, 0.47} OFF (0) or On (1)
RO Bit NC PT
1.13 Jog selected indicator {di13, 0.48} OFF (0) or On (1)
RO Bit NC PT
1.14 Reference selector {SE05, 0.26} 0 to 6 0 (A1.A2) RW Txt US
1.15 Preset selector 0 to 9 0 RW Uni US
1.16
Preset reference selector
timer
0 to 400.0s 10.0 RW Uni US
1.17 Keypad control reference ±MAX_SPEED_REF rpm 0.0 RO Bi NC PT PS
1.18 Precision reference coarse ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.19 Precision reference fine 0.0 to 0.099 rpm 0.000 RW Uni US
1.20
Precision reference update
disable
OFF (0) or On (1) OFF (0) RW Bit NC
1.21 Preset reference 1 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.22 Preset reference 2 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.23 Preset reference 3 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.24 Preset reference 4 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.25 Preset reference 5 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.26 Preset reference 6 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.27 Preset reference 7 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.28 Preset reference 8 ±MAX_SPEED_REF rpm 0.0 RW Bi US
1.29 Skip reference 1 0 to 10,000 rpm 0 RW Uni US
1.30 Skip reference band 1 0 to 250 rpm 5 RW Uni US
1.31 Skip reference 2 0 to 10,000 rpm 0 RW Uni US
1.32 Skip reference band 2 0 to 250 rpm 5 RW Uni US
1.33 Skip reference 3 0 to 10,000 rpm 0 RW Uni US
1.34 Skip reference band 3 0 to 250 rpm 5 RW Uni US
1.35 Reference in rejection zone OFF (0) or On (1)
RO Bit NC PT
1.36 Analog reference 1 ±MAX_SPEED_REF rpm 0 RO Bi NC
1.37 Analog reference 2 ±MAX_SPEED_REF rpm 0 RO Bi NC
1.38 Percentage trim ±100.00% 0.00 RW Bi NC
1.39 Velocity feed forward ±10,000.0 rpm
RO Bi NC PT
1.40 Velocity feed forward select OFF (0) or On (1)
RO Bit NC PT
1.41 Reference select flag 1 OFF (0) or On (1) OFF (0) RW Bit NC
1.42 Reference select flag 2 OFF (0) or On (1) OFF (0) RW Bit NC
1.43 Reference select flag 3 OFF (0) or On (1) OFF (0) RW Bit NC
1.44 Reference select flag 4 OFF (0) or On (1) OFF (0) RW Bit NC
1.45 Reference select flag 5 OFF (0) or On (1) OFF (0) RW Bit NC
1.46 Reference select flag 6 OFF (0) or On (1) OFF (0) RW Bit NC
1.47 Reference select flag 7 OFF (0) or On (1) OFF (0) RW Bit NC
1.48 Reference timer reset flag OFF (0) or On (1) OFF (0) RW Bit NC
1.49 Reference selected indicator 1 to 6
RO Uni NC
1.50
Preset reference selected
indicator
1 to 8
RO Uni NC PT
1.51
Power-up keyboard control
mode reference
0 to 2 0 RW Txt US
1.52 Reference select flags OFF (0) or On (1) OFF (0) RW Bit NC
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
