Process Variables…
The “Process Variables…” link displays the current reading of the process
variables measured by the 3095. In the “Process Variables…” window,
variables are automatically updated every 2-3 seconds. All values on the
screen are read-only.
1. Right-click on the transmitter icon.
2. Select “Process Variables…” from the pop-up menu.
The following process variables are viewable on the “Process Variables…”
window (see Figure 3-8):
• Absolute/Gage Pressure
• Differential Pressure
• Temperature
•Flow Rate
• Flow Total
• Analog Output (4-20mA)
Figure 3-8. Process Variables
Window (with 3095 Device
Driver File DD2 Rev 3)
