8.5 Calibrate the analog outputs
Complete the following steps to calibrate the analog outputs in the Rosemount 56
transmitter.
Procedure
1. Choose the appropriate output in Entering the Calibration menus and follow the
prompts to trim the selected output.
If you want more information about a calibration step, press INFO.
If the calibration is successful, the Trim complete screen appears. If the entered
value is more than 1.0 mA different from the simulated current output, the
transmitter displays the Possible error screen, and you are asked to accept the
calibration.
2. Press INFO for an information screen to aid with troubleshooting if the calibration
not acceptable.
8.6 Reset
8.6.1 Purpose
There are three resets.
1. Reset all user settings, including calibration and program settings, to the factory
default values. The transmitter will return to Quick Start.
Important
The event logger and data logger will be unaffected.
2. Reset sensor calibration to the default value. The transmitter will clear all user-
entered calibration data for the selected sensor. It will leave all other user-entered
data unaffected.
3. Reset the analog output calibration for the selected output to the default value. The
transmitter will leave all other user-entered settings unchanged.
8.6.2 Reset
There are three resets.
1. Reset all user settings, including calibration and program settings, to the factory
default values. The transmitter will return to Quick Start.
Important
The event logger and data logger will be unaffected.
2. Reset sensor calibration to the default value. The transmitter will clear all user-
entered calibration data for the selected sensor. It will leave all other user-entered
data unaffected.
3. Reset the analog output calibration for the selected output to the default value. The
transmitter will leave all other user-entered settings unchanged.
Procedure
1. With the main display showing, press ENTER/MENU to display the main menu.
Reference Manual Calibrate
00809-0200-3415 January2023
