3 Installation
3.1 Unpacking and inspection
Procedure
1. Inspect the shipping container(s). If there is damage, contact the shipper
immediately for instructions.
2. If there is no apparent damage, unpack the container(s).
3. Ensure that all items shown on the packing list are present.
If items are missing, notify Emerson immediately.
3.2 Installation
3.2.1 General installation information
1. Although the system is suitable for outdoor use, do not install it in direct sunlight or
in areas of extreme temperature.
CAUTION
Hazardous areas
The system is not suitable for use in hazardous areas.
2. Install the system in an area where vibrations and electromagnetic and radio
frequency interference are minimized or absent.
3. The transmitter is suitable for panel, pipe, or wall mounting. The sample
conditioning enclosure must be mounted on a wall. Provide adequate room beneath
the enclosure for the 5-gallon reagent carboy.
4. Be sure that the distance between the transmitter and sample conditioning cabinet
does not exceed the length of the sensor cable.
3.2.2 Install the sample conditioning enclosure
Follow the steps below to install the sample conditioning enclosure.
Refer to Figure 3-1, Figure 3-2, and Figure 3-3 for installation details.
Reference Manual Installation
00809-0200-3415 January2023
Rosemount TCL 56 11
