Empire Mantis BF28BM-5 - Bay Window Mantis Specifications

28743-0-0711 Page 21
35-7/16”
OR
38”
LOUVER
29-3/4”
5-15/16”
23-13/16”
10-1/8”
6-13/16”
PV-4H
(SHORTTOP
COVER KIT)
3-9/16”
16-15/16”
BAY WINDOW MANTIS SPECIFICATIONS - (continued)
35-7/16”
OR
38”
LOUVER
29-3/4”
5-15/16”
23-13/16”
PV-2H
(SLIM TOP
COVER KIT)
11-5/16”
3”
3-9/16”
6”
Fireplace Insert with Mantel Surround with PV-2H Slim Top Cover Kit
Figure 30
Fireplace Insert with Mantel Surround with PV-4H Short Top Cover Kit
Figure 31
Rear View
Figure 32
FLUE OUTLET
AIR INLET
ELECTRIC
CORD
13/16”
1”
7-5/16”
2-13/16”
1-7/16”
3-9/16”
1-1/2”
6-1/8”
FLEX HOSE
OPENING
