28743-0-0711Page 42
BAY WINDOW MANTIS PARTS LIST
INDEX
NO.
PART
NO.
DESCRIPTION
1 27072 REAR PANEL ASSEMBLY
2 21654 BRACKET, PIPE ASSEMBLY
3 24831 REAR HEAT SHIELD ASSEMBLY
4A 21664
TOP COVER ASSEMBLY
(INCLUDES #5)
4B 22933 SLIM TOP ASSEMBLY
4C 22934 SHORT TOP ASSEMBLY
5 R8854 BALL STUD
6 22693 TOP HEAT SHIELD ASSEMBLY
7 21637 FIREBOX ASSEMBLY
8 26089
HEAT EXCHANGER TUBE
ASSEMBLY
9 R10337 GASKET, END PLATE
10 R9987 FLEX LINE - 24”
11 26087
SUMP ASSEMBLY
(INCLUDES #12 & #14)
12 22863
BLOWER ASSEMBLY
(INCLUDES #14)
13 R10299 SWITCH, BIMETALIC
14 R8795 GASKET, SUMP
15 26090 FIN TUBE ASSEMBLY
16 R8811 GASKET, INLET HEADER
17 R10966 TUBING (SUMP TO PUMP)
18 21652
TUBING (SUMP TO PRESSURE
SWITCH)
19 21627 SHIELD, REAR INNER
20 25227 ELECTRIC PARTS PLACE
21 21667 LEFT SIDE DOOR ASSEMBLY
22 22642 TUBE, CONDENSATE
23 21647
CONNECTOR TUBING ASSEMBLY
(PUMP TO CONDENSATE TUBE)
24 21605 COVER, INLET AIR DUCT
25 22780 INLET AIR DUCT ASSEMBLY
26 R10491 GASKET, INLET AIR DUCT
27 21641
BRACKET ASSEMBLY THERMISTER
(SPRING CLIP INCLUDED)
28 R4053 CLAMP, DOOR (4 USED ON UNIT)
29 22773 THERMISTER ASSEMBLY
30 R10488 3/8 ELBOW, 90
32 26789 BOTTOM PAN ASSEMBLY
33 26123 INLET HEADER
34 21665 RIGHT SIDE DOOR ASSEMBLY
35 21651
TUBING (FIREBOX TO PRESSURE
SWITCH)
36 R8835 FITTING, BARBED HOSE
37 22865
IGNITOR, HOT SURFACE
ASSEMBLY
38 21611 BRACKET, IGNITOR
39 R8807 FLAME SENSOR
40 26800 LOG PLATE ASSEMBLY
41 26787
SMALL BURNER ASSEMBLY LP (IN-
CLUDES R10675 AND #44)
41 22753
SMALL BURNER ASSEMBLY NAT
(INCLUDES #43 AND #44)
42 26801
LARGE BURNER ASSEMBLY - LP
(INCLUDES #44 AND R10676)
42 22658
LARGE BURNER ASSEMBLY - NAT
(INCLUDES #44 AND R10675)
43 R9831
BUSHING, AIR SHUTTER
(NAT ONLY)
44 R8790 BUSHING, BURNER
45 P208 REAR ORIFICE, LPG
45 P288 REAR ORIFICE, NAT
46 P208 FRONT ORIFICE, NAT
46 P307 FRONT ORIFICE, LPG
47 R10796 HOLDER, ORIFICE
48 R7572 JAMB NUT
49 27071 GAS LINE - REAR
INDEX
NO.
PART
NO.
DESCRIPTION
WARNING
Use only manufacturer’s replacement parts. Use of any other parts could cause injury or death.
