28743-0-0711 Page 7
Bay Window Mantis Models B(F,I,P)28(B,C,G)M(N,P)
Input BTU/HR (KW/H) 19,000 Rear - 9,000 Front
Height 25-1/4”
Width 28”
Depth 17-5/8”
Gas Inlet (Pipe) 3/8” Flair
Electrical - The unit comes equipped with a 5 foot (1.5 m)
3 pronged cord, for connection to an approved
115 VAC, 60 Hz , 5A (maximum) wall receptacle.
Vent Pipe: - 1-1/2 inch diameter schedule 40 PVC pipe, 40 feet
maximum equivalent length.
SPECIFICATIONS & ACCESSORIES
Fireplace Mantis Models F(F,I,W)28BM(N,P)
Input BTU/HR (KW/H) 15,000 Rear - 13,000 Front
Height 24-9/16”
Width 28”
Depth 17-3/16”
Gas Inlet (Pipe) 3/8” Flair
Electrical - The unit comes equipped with a 5 foot (1.5 m) 3
pronged cord, for connection to an approved
115 VAC, 60 Hz, 5A (maximum) wall receptacle.
Vent Pipe: - 1-1/2 inch diameter schedule 40 PVC pipe, 40 feet
maximum equivalent length.
ACCESSORIES
Common
Part Number Description
TRW Wall Thermostat - Wireless Remote
FRBTP Battery Operated Remote with Programmable Thermostat
PVCA Colinear Adapter
PVCT Colinear Transition Kit
PVVK-CFA Flex Vent Kit
PVVK-SH Single Flue Horizontal Vent Kit
PVVK-SV Single Flue Vertical Vent Kit
PVVTC Vertical Termination Cap - 1-1/2”
PVVK24H Coaxial Horizontal Direct Vent Kit (24”)
PVVK48H Coaxial Horizontal Direct Vent Kit (48”)
Bay Window Mantis
CIFPB-1C Corner Floor Pad Kit
CIPFP-1 Floor Pad Kit
PV-2H Slim Top Cover Kit
PV-4H Short Top Cover Kit
PVE-1 Metal Surround Kit, 35”
PVE-2 Metal Surround Kit, 38”
PVPK Pedestal Kit
PVSH Rear Shroud
Fireplace Mantis
FWK28(BL,CM,HP,SS) In-Wall Surround Kit, Picture Frame
FGK28(BL,SS) In-Wall Surround Kit, Louverless
FIK28(BL,CM,HP,SS) Insert Package
FFK28(BL,CM,HP,SS) Fireplace Mantel Surround Kit
