Empire Mantis BF28BM-5 - Bay Window Mantis Parts List

28743-0-0711 Page 43
BAY WINDOW MANTIS PARTS LIST
50 26128 GAS LINE - FRONT
51 M174 GASKET
52 11269 GAS LINE BRACKET
53 R8886 COMPRESSION FITTING
54 R8812 VALVE, NAT
54 R8869 VALVE, LPG
55 R8898 PIPE NIPPLE
56 R8825 SOLENOID
57 R3312 CONNECTOR, MALE 3/8 X 3/8
59 R10072 SHUT-OFF VALVE
60 21643 FIREBOX BASE ASSEMBLY
61 R10775 CONTROL BOX ASSEMBLY
62 R8889 TRANSFORMER 12-24V
63 R8804 TRANSFORMER 24V
64 25325 CONDENSATE PUMP COVER
67 27004 CIRCULATING BLOWER ASSEMBLY
68 21663 DOOR ASSEMBLY, BLACK
68 22758 DOOR ASSEMBLY, CHROME
68 22759 DOOR ASSEMBLY, GOLD
69 26582 FRONT PANEL ASSEMBLY
70 R8840
WIRE HARNESS ASSEMBLY
WITH ECONOMY SWITCH
71 R8809 SWITCH, DOUBLE ROCKER
72 R8904 CIRCUIT BOARD
73 25226 CIRCUIT BOARD PLATE
74 R10759 RIBBON CABLE
75 R11043 CIRCUIT BOARD WIRE HARNESS
76 R10182 WIRE HARNESS, 120V
77 R10183 WIRE HARNESS 12V
78 R10190 WIRE HARNESS 12V
79 26075 PUMP ASSEMBLY
80 R10489 AIR PRESSURE SWITCH
81 R8881 CAPACITOR 3uF
82 R8880 CAPACITOR 4uF
84 R10485 LOG, LEFT REAR
85 R8822 LOG, TOP LEFT
86 R10487 LOG, TOP RIGHT
87 R10486 LOG, RIGHT
88 R8820 LOG, CENTER
89 R8819 LOG, FRONT LEFT
90 R8821 LOG, FRONT RIGHT
91 R2522 MAIN POWER SWITCH
92 R10610
WIRE HARNESS, MAIN POWER
SWITCH
93 26119 HEADER COVER - OUTLET
94 26123 HEADER COVER - INLET
NOT
SHOWN
R10675 BUSHING, AIR SHUTTER
NOT
SHOWN
R10676 BUSHING, AIR SHUTTER
NOT
SHOWN
FRBTC THERMOSTAT
INDEX
NO.
PART
NO.
DESCRIPTION
INDEX
NO.
PART
NO.
DESCRIPTION
WARNING
Use only manufacturer’s replacement parts. Use of any other parts could cause injury or death.
