Empire Mantis BF28BM-5 - Fireplace Mantis Specifications

28743-0-0711Page 22
35”
33-7/16”
35”
29-3/8”
Heater In Wall - 35 Inch Picture Frame Surround
FWK28(BL,CM,HP,SS) - Contains surround, hood, and lower
front
Heater - 35 Inch Surround Kit
FFK28(BL,CM,HP,SS) - Contains surround, hood, & lower front
Figure 35
Figure 36
Figure 33
Heater with Flex Vent
PVVK-CFA
FLEX VENT KIT
23-1/2”
24-3/4”
MIN.
6-1/2”
FIREPLACE MANTIS SPECIFICATIONS
17-3/16”
3-9/16”
FLUE OUTLET
24-3/4” MIN
Figure 34
