Empire Mantis BF28BM-5 - Page 47

28743-0-0711 Page 47
FIREPLACE MANTIS PARTS LIST
52 R10182 WIRE HARNESS - 120V
53 R10190 WIRE HARNESS - 12V SMALL
54 R10183 WIRE HARNESS - 12V LARGE
55 R8814 THERMISTER
57 R8872 WIRE HARNESS
58 R10759 RIBBON CABLE
59 24831
REAR HEAT SHIELD
ASSEMBLY
60 22642 CONDENSATE PUMP TUBE
61 25325 CONDENSATE PUMP COVER
R10077 LOG SET (INCLUDES 62 - 69)
62 R10376 REAR LOG
63 R10381 LEFT LOG
64 R10380 RIGHT LOG
65 R10379 MIDDLE LOG
66 R10378 FRONT LEFT LOG
67 R10377 FRONT RIGHT LOG
68 R10383 LEFT TOP LOG
69 R10382 RIGHT TOP LOG
70 25216
BRACKET, STANDOFF
(2 REQUIRED)
71 R2522 MAIN POWER SWITCH
73 R10610
WIRE HARNESS,
MAIN POWER SWITCH
74 R8795 GASKET - SUMP
75 26119 HEADER COVER - OUTLET
76 26123 HEADER COVER - INLET
INDEX
NO.
PART
NO.
DESCRIPTION
WARNING
Use only manufacturer’s replacement parts. Use of any other parts could cause injury or death.
NOT
SHOWN
R10093 ORIFICE #47 - NAT
NOT
SHOWN
R10094 ORIFICE #49 - NAT
NOT
SHOWN
R10095 ORIFICE #1.2MM - LP
NOT
SHOWN
R10096 ORIFICE #55 - LP
NOT
SHOWN
26117
AIR DUCT CHANNEL COVER PLATE
- NAT ONLY
NOT
SHOWN
R10299 SWITCH, BIMETALIC
NOT
SHOWN
FRBTC THERMOSTAT
NOT
SHOWN
R10966 TUBING (SUMP TO PUMP)
INDEX
NO.
PART
NO.
DESCRIPTION
