Encore ENHWI-G3 User Manual

Features
9 Compliant with IEEE 802.11g and 802.11b Devices
9 Built-in 4 x 10/100Mbps Auto-MDIX LAN Ports
9 Built-in 1 x 10/100Mbps Auto-MDIX WAN Port (Internet)
9 Supports Cable/DSL Modems with Dynamic IP, Static IP, PPPoE, L2TP, PPTP or BigPond
Connection Types
9 DHCP Server Feature Allocates up to 253 Client IP Addresses
9 Supports 64/128-bit Wired Equivalent Privacy (WEP)
9 Supports WPA, WPA2, WPA-PSK and WPA2-PSK Advanced Security
9 Supports MAC Address, Protocol Filters and UPnP (Universal Plug & Play)
9 Traffic Control with Virtual Server, Virtual PC mapping and DMZ
9 Provides Additional Security with SPI / NAT firewall and Attack Alert via emails
9 Provides Additional Security of Enable/Disable SSID, Password Protection
9 Flash Memory for Firmware Upgrade, Save/Restore Settings, and Traffic Log
9 Compliant with Windows 95/98/NT/2000/XP, Linux and Mac OS
9 Easy Management and Remote Management via Web Browser (HTTP)
9 Range for Indoor of 30 ~ 50 meters (depends on the environment)
9 Range for Outdoor of 50 ~ 200 meters (depends on the environment)
3

Encore ENHWI-G3 Specifications

Transmission and Reception

transmission rate (802.11b)	1, 2, 5.5, 11 Mbps
transmission rate (802.11g)	6, 12, 24, 36, 48, 54 Mbps
receiver sensitivity (54Mbps)	-70 @ 10% PER
receiver sensitivity (11Mbps)	-85 @ 8% PER
wireless LAN frequency range	2412 ~ 2484 MHz

Transmit Power and Antennas

transmit power (802.11b)	15±2 dBm
transmit power (802.11g)	13±2 dBm
antenna type	Dual diversity antennas
external antenna gain	2 dB

Interface and Ports

LAN ports	4 x 10/100 Mbps Auto-MDIX Ethernet ports
WAN port	1 x 10/100 Mbps Auto-MDIX Ethernet port
interface	LAN, WAN

Power and Temperature

power adapter voltage	7.5 V
power adapter current	1 A
operation temperature	0 ~ 40 °C
storage temperature	-10 ~ 70 °C

Dimensions and Environmental

dimensions (W x H x D)	147 x 115 x 35 mm
range coverage indoor	Up to 30 meters
range coverage outdoor	Up to 100 meters
humidity	10% ~ 95% RH, no condensation
