Technical data Cerabar PMC11, PMC21, PMP11, PMP21, PMP23
38 Endress+Hauser
Overview of the turn down ranges → 32
Measuring ranges Turn down Device % of URL
100 mbar (1.5 psi)to
40 bar (600 psi)
1:1 to TD 5:1 PMC11 ±0.5
PMC21 ±0.3
1)
1) For the 100 mbar (1.5 psi) and 250 mbar (4 psi) measuring ranges, the following applies: In the event of
heat effects on the initial reference conditions, an additional deviation of max. 0.3 mbar (4.5 psi) from the
zero point or the output span is possible.
12.3.6 Thermal change of the zero output and the output span
Measuring cell –20 to +85 °C (–4 to +185 °F) –40 to –20 °C (–40 to –4 °F)
+85 to +100 °C (+185 to +212 °F)
% of URL for TD 1:1
<1 bar (15 psi) <1 <1.2
≥ 1 bar (15 psi) <0.8 <1
12.3.7 Long-term stability
1 year 5 years 8 years
% of URL
±0.2 ±0.4 ±0.45
12.3.8 Switch-on time
≤2 s (For small measuring ranges, pay attention to the thermal compensation effects.)
