Deltabar PMD78B PROFINET with Ethernet-APL Mounting
Endress+Hauser 29
NOTICE
The housing cannot be unscrewed fully.
‣
Loosen the external locking screw by a maximum of 1.5 turns. If the screw is
unscrewed too much or completely (beyond the screw anchor point), small parts
(counter disk) can become loose and fall out.
‣
Tighten the securing screw (hex socket 4 mm (0.16 in)) with maximum
3.5 Nm (2.58 lbf ft) ± 0.3 Nm (0.22 lbf ft).
5.3 Post-mounting check
Is the device undamaged (visual inspection)?
Are the measuring point identification and labeling correct (visual inspection)?
Is the device protected against precipitation and direct sunlight?
Are the securing screws and cover lock tightened securely?
Does the measuring device meet the measuring point specifications?
For example:
• Process temperature
• Process pressure
• Ambient temperature
• Measuring range
