Deltabar PMD78B PROFINET with Ethernet-APL Technical data
Endress+Hauser 83
15 Technical data
15.1 Output
Output signal PROFINET with Ethernet-APL
10BASE-T1L, 2-wire 10 Mbit
Signal on alarm Signal on alarm in accordance with NAMUR recommendation NE 43.
PROFINET with Ethernet-APL:
• According to "Application Layer protocol for decentralized periphery", Version 2.4
• Device diagnostics according to PROFINET PA Profile 4.02
Damping A damping affects all outputs (output signal, display). Damping can be enabled as follows:
• Via the onsite display, Bluetooth, handheld terminal or PC with operating program,
continuous from 0 to 999 seconds
• Factory setting: 1 s
Ex connection data See the separate technical documentation (Safety Instructions (XA)) on
www.endress.com/download.
Linearization The device's linearization function allows the user to convert the measured value to any
units of height or volume. User-defined linearization tables of up to 32 value pairs can be
entered if necessary.
Protocol-specific data PROFINET with Ethernet-APL
Protocol Application layer protocol for decentral device periphery and distributed
automation, Version 2.4
Communication type Ethernet Advanced Physical Layer 10BASE-T1L
Conformance Class Conformance Class B
Netload Class Netload Class II
Baud rates Automatic 10 Mbit/s with full-duplex detection
Cycle times From 32 ms
Polarity Auto-polarity for automatic correction of crossed TxD and RxD pairs
Media Redundancy Protocol
(MRP)
Yes
System redundancy support System redundancy S2 (2 AR with 1 NAP)
Device profile Application interface identifier 0xB310
Generic device
Manufacturer ID 0x11
Device type ID A231
Device description files (GSD,
FDI, DTM, DD)
Information and files at:
• www.endress.com
On the product page for the device: Documents/Software → Device drivers
• www.profibus.org
