Commissioning
45
Engineering Unit Technical unit of the count input, e.g. liters, m, etc. Only active for the functions "Pulse
Counter", "Operational Time" and "Event+Operation Time". This value can only be
changed for the "Pulse Counter" function. 6-character entry.
Decimal Point Number of places after decimal point for the display. Picklist: 0 to 5
number of places after the decimal point. Only active for "Impulse Counter" function.
Factory setting: one (XXXX.X)
1 impulse = Pulse factor = factor which, when multiplied by the input pulse, results in the required
physical value. Example: 1 pulse equals 5 m –> enter "5". Only active for "Pulse
Counter" function. Factory setting: 1.0
Description 'H' Description of the status if the digital input is activated. This text is both shown in the
display and saved to memory. Only active for "On/Off Event" and "Event+Operation
Time" functions. Factory setting: on
Description 'L' Description of the status if the digital input is not activated. This text is both shown in
the display and saved to memory. Only active for "On/Off Event" and "Event+Operation
Time" functions. Factory setting: off
Message Window "Do Not Display": no message is output when the digital input switches.
"Display+Acknowledge": a message window is displayed that has to be acknowledged
by pressing a key.
Only active for "On/Off Event" and "Event+Operation Time" functions.
Save Event Determines whether the condition change from low to high or high to low is stored in
the event list. Note: increased memory capacity needed.
Only active for "On/Off Event" and "Event+Operation Time" functions.
Picklist: Yes, No
Event Text L->H Description of condition change from low to high. Event text is stored (e.g. start filling).
22-character entry. Only active for "Event+Operation Time" and "On/Off Event"
functions.
Event Text H->L Description of condition change from high to low. Event text is stored (e.g. stop filling).
22-character entry. Only active for "Event+Operation Time" and "On/Off Event"
functions.
Total/Year Count. Preset for the totalizer/yearly counter. Useful when continuing a measurement
performed to date with an electromechanical counter. 13-character entry. Only active
for "Pulse Counter", "Operational Time" and "Event+Operation Time" functions.
Factory setting: 0
Display Counter values are saved in specific time cycles (e.g. daily, monthly, ... - see "Signal
analysis"). Here you can select the counter type that is to be constantly displayed.
Picklist: Intermediate Counter:, Daily Counter, Monthly Counter, Total/Yearly
Counter. Only available for "Impulse Counter", "Operating Time" and "Events +
Operating Time" functions.
Copy Settings Copies settings from actual channel to selected channel.
Picklist: No, in Digital Input x
"Signal Settings"
menu items
Configurable parameters
(factory settings are highlighted in bold)
