Commissioning Liquisys M CPM223/253
68 Endress+Hauser
R268
Enter maximum
pulse frequency of
the adjuster
120 min
-1
60 to 180 min
-1
This field only appears if pulse frequency
is selected in R266.
If pulse length is selected, R268 is skipped
and entries continue with R269.
R269
Enter minimum
switch-on time t
ON
0.3 s
0.1 to 5.0 s
This field only appears if pulse length is
selected in R266.
R2610 Enter process type
Batch
Inlne
Batch = discontinuous process
Inlne = continuous process
There is no further dosing in the setting
range in batch mode. The I-component is
decreased.
Dosing continues in the setting range in
inline mode. The I-component is effective.
Coding Field Setting range
(Factory settings, bold)
Display Info
R268
1/min
Max.PFreq
120
R269
s
Min.PTime
0.3
R2610
%
Proc.Type
Batch
