Repair Liquisys M CPM223/253
94 Endress+Hauser
Item Kit description Name Function/contents Order number
10 Power unit LSGA 100 / 115 / 230 V AC 51500317
20 Power unit LSGD 24 V AC + DC 51500318
30 Jumper Part of power unit, item 10
40 Central module LSCH-S1 1 current output 51501081
40 Central module LSCH-S2 2 current outputs 51501082
40 Central module LSCH-H1 1 current output + HART 51501083
40 Central module LSCH-H2 2 current outputs + HART 51501084
40 Central module LSCP PROFIBUS PA/no current output 51501085
40 Central module LSCP PROFIBUS DP/no current output 51502503
40 Kit CPM2x3 Central module
PROFIBUS DP
LSCP-DP Central module PROFIBUS DP
Relay module + 2 relays
Current input and terminals
valid of: hardware version 2.10
71134724
230 pH/mV transmitter MKP1 pH/mV + temperature input
Glass electrode
51501080
230 pH/mV transmitter MKP2 pH/mV + temperature input ISFET
sensor
51507096
230 pH/mV transmitter MKP3 pH/mV + temperature input
Glass electrode
software versions 2.55 HART,
2.33 PROFIBUS or newer
51518244
230 Memosens-transmitter MKD1 digital input 51514966
235 pH/mV input BNC connection jack + screening
plate
51501070
290 Relay module LSR1-2 2 relays 51500320
290 Relay module LSR2-2i 2 relays + current input 4 to 20 mA 51504304
290 Kit CxM2x3 Relay module
PROFIBUS DP
LSR2-DP Relay module + 2 relays
Current input and terminals DP
valid of: hardware version 2.10
71134732
300 Relay module LSR1-4 4 relays 51500321
300 Relay module LSR2-4i 4 relays + current input 4 to 20 mA 51504305
310 Side panel Kit with 10 parts 51502124
310, 320,
340, 400
Housing mechanical parts Rear plate, side panel, end frame,
special screw
51501076
330, 400 Housing module Housing with front membrane,
sensory tappets, gasket, special
screw, tensioning dogs, connection
plates and nameplates
51501075
340 End frame Rear frame for PROFIBUS DP, with D-
submin plug connector
51502513
zu 340 PE terminal PE terminal for screen grounding for
IS version
51501086
422a,
422b
Terminal strip set Complete terminal strip set, standard
+ HART
51501077
422a,
422b
Terminal strip set Complete terminal strip set,
PROFIBUS PA
51501077
422a,
422b
Terminal strip set Complete terminal strip set,
PROFIBUS DP
51502494
430 Terminal strip Terminal strip for relay module 51501078
435 BNC connector, elbowed pH/mV connection 50074961
