INSTALLATION AND MAINTENANCE
Mounting the Thermostat
Install the thermostat at 5 feet (1.5m) above the floor in an area with good air circulation at average
temperature. Avoid locations with drafts or dead spots behind doors, hot or cold air ducts, sunlight
or radiant heat from appliances, concealed pipes or chimneys and unconditioned areas such as
outside walls behind the thermostat.
The 2 wallplate anchors should be spaced 3.5 inches (90 mm) apart in a vertical direction. Pull
wires through the backplate and connect to the appropriate terminals as defined in the Wiring
Configuration.
Mounting the Outdoor Sensor
The outdoor sensor should be mounted in a shaded location, out of direct sunlight. The thermostat
will automatically detect the outdoor sensor and display its readings.
Cleaning the Thermostat
The thermostat can be cleaned with a soft cloth lightly dampened with isopropyl alcohol (IPA).
Excessive IPA or use of other solvents may damage the LCD!
