Energate Z100 P2 - Wiring Configuration

Wiring Configuration
The thermostat should be wired by a licensed technician familiar with HVAC installation.
1C
2
3 RS OUT Outdoor Sensor
4 RS GND Sensor Ground
5 FILTER Filter
6
7
1
2 FAULT Heat Pump Fault
3 RS OUT Outdoor Sensor
4 RS GND Sensor Ground
5 FILTER Filter
1s
6
2n
7 C
Conventional System
Heat Pump System
ommon(GND) C8
Power (24VAC) R 9
1st Stage Heat W1 10
Fan G 11
1st Stage Cool Y1 12
2nd Stage Cool Y2 13
2nd Stage Heat W2 14
Common (GND) C 8
Power (24VAC) R 9
Auxiliary Heat E 10
Fan G 11
t Stage Heat Pump
Y1 12
d Stage Heat Pump
Y2 13
hangeover Valve O/B 14
s (CONV)
s (HP)
