INSTALLATION AND MAINTENANCE
Mounting the Thermostat
Install the thermostat approximately 5 feet (1.5m) above the floor in an area with good air circulation
at average temperature. Avoid locations with drafts or dead spots behind doors, hot or cold air
ducts, sunlight or radiant heat from appliances, concealed pipes or chimneys and unconditioned
areas such as outside walls behind the thermostat.
The 2 wallplate anchors should be spaced 3.46 inches (88 mm) apart in a vertical direction. Pull
wires through the backplate and connect to the appropriate terminals as defined in the Wiring
Configuration.
WARNING:
During handling, take care not to bend the thermostat, and not to press hard on the
front surface of the thermostat.
Whenever the backplate is off the thermostat, take care not to touch the exposed electronic
components. Electrostatic discharge can damage sensitive components.
