Setpoint Range
The SETPOINT RANGE sub menu defines the Maximum and Minimum temperatures allowed in
the HEAT and COOL modes. Adjusting these temperatures limits the temperature ranges allowed
when setting SETPOINT temperatures.
Equipment Type
WARNING: The thermostat must be configured correctly to match the equipment type. The number
of cooling and heating stages must be defined in the Conventional or Heat Pump setting.
EQUIPMENT TYPE
DEFAULT
OPTION
CONVENTIONAL
# OF COOL STAGES
1
0-2
# OF HEAT STAGES
1
0-2
HEAT PUMP
# OF COOL STAGES
1
1-2
# OF HEAT STAGES
1
1-3*
REV. VALVE
ON IN COOL
ON IN HEAT
*For Heat Pumps, defining one more heat stage than cool stage(s) indicates that Emergency Heat
(Auxiliary Heat) is installed.
