Mounting the Thermostat (continued)
Remove back-plate from thermostat housing.
Grab battery-tab and pull away from the
battery.
Do not touch the ESD-sensitive components
unless properly grounded
Place thermostat housing as shown
above.
It is very important to engage the top
hinge first.
